Miniature NBR O-Rings
Miniature NBR O-rings are designed for compact grooves, small valves, micro-pumps and precision assemblies where dimensional control is critical. Hongjie supports sizes from ID 0.60 × CS 0.20 mm to ID 25.00 × CS 3.00 mm, with 30–90 Shore A hardness options and inspection available according to part size and project requirements.
Precision Miniature O-Rings for Compact Sealing
Small O-rings require careful control of dimensions, surface condition and handling. This range is focused on compact NBR seals from ID 0.60 × CS 0.20 mm to ID 25.00 × CS 3.00 mm.
-
Miniature Size Range
Available from ID 0.60 × CS 0.20 mm up to ID 25.00 × CS 3.00 mm for compact grooves and small-component designs.
-
NBR Compound Options
NBR compounds are selected according to fluid exposure, operating temperature, hardness and sealing conditions.
-
ZEON Material Options
ZEON NBR material options are available for projects that specify this material source or require controlled compound selection.
-
30–90 Shore A Hardness
Hardness can be specified from 30 to 90 Shore A according to groove geometry, compression and application requirements.
-
Surface Control
Surface condition, flash and parting-line appearance are reviewed according to part dimensions and functional requirements.
-
Inspection Options
Dimensional, visual and automatic inspection options can be reviewed according to part size, tolerance and detectable defect requirements.
Specifications & Materials
Key specifications for miniature NBR O-rings are listed below. Final compound, tolerance and inspection requirements should be confirmed against the drawing and application.
| Product Specifications | |
|---|---|
| Product Name | Miniature NBR O-Rings |
| Category | Miniature O-Rings |
| Compound Material | ASTM D2000 options available where specified |
| Compliance Options | Available according to selected compound and documentation requirements |
| Material | NBR |
| Material Brand | ZEON options available |
| Hardness | 30–90 Shore A |
| Color | Black standard; custom colors subject to compound and project requirements |
| Inside Diameter (ID) Range | 0.60 mm–25.00 mm |
| Cross Section (CS) Range | 0.20 mm–3.00 mm |
| Larger Sizes | For sizes above ID 25 mm or drawing-based non-standard development, see our Custom Rubber O-Rings. |
| Sample Lead Time | Confirmed by size, tooling and sample requirements |
| Mass Production Lead Time | Confirmed after specification and quantity review |
| Application | Compact grooves, valves, pumps, sensors and precision assemblies |
| Surface Quality | Defined by drawing or approved sample |
| Inspection | Dimensional, visual and automatic inspection options by part size |
| Customization | Drawing, sample and specification-based production |
Specification Options
Miniature NBR O-Ring Size Chart (CS × ID)
Miniature O-rings are specified by cross section (CS) and inside diameter (ID). The table below shows the current miniature manufacturing range. Non-standard combinations can be reviewed separately.
| CROSS SECTION (CS) | AVAILABLE ID RANGE |
|---|---|
| 0.20 mm | 0.60–3.00 mm |
| 0.30 mm | 0.70–4.00 mm |
| 0.40 mm | 0.80–5.00 mm |
| 0.50 mm | 1.00–6.00 mm |
| 0.60 mm | 1.20–8.00 mm |
| 0.80 mm | 1.50–10.00 mm |
| 1.00 mm | 2.00–12.00 mm |
| 1.20 mm | 2.50–15.00 mm |
| 1.50 mm | 3.00–18.00 mm |
| 1.80 mm | 3.50–20.00 mm |
| 2.00 mm | 4.00–22.00 mm |
| 2.50 mm | 5.00–25.00 mm |
| 3.00 mm | 6.00–25.00 mm |
Dimensional Tolerances
The following values describe current manufacturing reference ranges. Final tolerances are confirmed against the drawing, compound, tooling condition and measurement method.
| CS RANGE (MM) | CS TOLERANCE | ID RANGE (MM) | ID TOLERANCE |
|---|---|---|---|
| 0.20–0.50 | ±0.03 mm | 0.60–3.00 | ±0.05 mm |
| 0.51–0.80 | ±0.04 mm | 3.01–5.00 | ±0.06 mm |
| 0.81–1.00 | ±0.05 mm | 5.01–8.00 | ±0.08 mm |
| 1.01–1.50 | ±0.06 mm | 8.01–12.00 | ±0.10 mm |
| 1.51–2.00 | ±0.08 mm | 12.01–20.00 | ±0.13 mm |
| 2.01–3.00 | ±0.09 mm | 20.01–25.00 | ±0.15 mm |
These values are manufacturing reference ranges rather than a blanket tolerance standard. Critical dimensions and acceptance criteria should be confirmed during specification review.
Inspection Focus for Miniature Parts
Inspection methods should match the actual part dimensions and the defects that need to be controlled. Automatic inspection can be evaluated according to cross section, contrast and detectable defect limits.
-
ID + CS
Dimensional Checks
-
Surface
Visual Criteria
Where Miniature NBR O-Rings Are Used
This range is intended for compact sealing positions where NBR is compatible with the working medium and available groove space is limited.
Handling and Assembly of Miniature O-Rings
Small O-rings can be damaged or misplaced more easily during assembly. Groove design, edge condition and handling method should be reviewed together with the nominal O-ring size.

-
Avoid Excessive Stretching
Do not stretch miniature O-rings more than necessary during installation, especially when the cross section is very small.
-
Protect Sharp Edges
Avoid burrs, sharp edges and exposed threads that may cut or nick the sealing surface during installation.
-
Keep Parts Clean
Use clean handling and storage conditions to prevent dust, fibers or oils from contaminating small sealing surfaces.
-
Check Groove Compatibility
Confirm groove dimensions, compression and installation clearance before finalizing the miniature O-ring size.
Frequently Asked Questions
Answers to common questions about miniature size limits, tolerances, inspection and specification review.
